MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300

Name: MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300
Brand: SANSEL INSTRUMENTS & CONTROLS
Price: 45500 INR
Availability: InStock

Price 45500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300 Specification

Connection
Digital display, RS232 interface

Accuracy
±0.3°C

Function
Temperature calibration of sensors and devices

Size
Miniature, compact design

Power Supply
230 V AC, 50 Hz

Insert Size
25 mm diameter x 120 mm depth

Block Material
Aluminum

Application
Calibration of thermocouples, RTDs, temperature switches, and other temperature measuring instruments

Display
4-digit LED display

Controller
Microprocessor-based PID controller

Stability
±0.1°C

Heating Time
Up to 300°C in approx. 12 minutes

Temperature Range
Ambient +5°C to 300°C

Weight
Approx. 2 kg

MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300 Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300

Model TCAL: 1404/300

Display: 2.8" True TFT with Touch screen

Temperature Range: Amb. +5 to 300C

Radial uniformity (Better than): 0.03C

Resolution: 0.01 C

Stability: 0.04 C

Temperature readout: C

Heating time: Amb to 300-->23min

Cooling time: 300 to 50 -->30 min

Stabilization time: 15 mins

Well Dimension (dia. x height): 20 x 100 mm

Well immersion depth: 90 mm

Standard well holes in mm: 6.2 x 2nos

Power supply 230V AC 10% / 50Hz (Optional 110V AC)

Power consumption 250 w

Overall Dimension in mm 170 x 95 x 183 mm

Instrument Weight 2.75 Kg

Compact Yet Powerful Calibration Solution

The TCAL 1404/300 stands out with its miniature, space-saving design without compromising on performance. Its lightweight profile and robust aluminum block make it easy to transport and set up in various environments, delivering consistent results for sensor calibration needs.

Rapid and Reliable Temperature Control

Equipped with advanced microprocessor-based PID control, the calibrator achieves fast heating-reaching its 300C maximum in approximately 12 minutes-while maintaining remarkable temperature stability (0.1C). This ensures swift and reliable calibration cycles without lengthy downtime.

User-Friendly Operation and Connectivity

With a clear 4-digit LED display and a digital RS232 interface, monitoring and controlling temperatures are straightforward tasks. The built-in controller allows precise temperature adjustment, giving professionals maximum control and ease of use in diverse calibration scenarios.

FAQ's of MINIATURE DRY BLOCK TEMPERATURE CALIBRATOR - TCAL 1404/300:

Q: How do I operate the TCAL 1404/300 miniature dry block temperature calibrator for sensor calibration?

A: To use the TCAL 1404/300, simply insert your temperature sensor into the provided aluminum block, set the desired temperature using the intuitive PID controller, and monitor the reading on the 4-digit LED display. Its quick heat-up ensures efficient calibration sessions.

Q: What types of sensors and instruments can this calibrator be used for?

A: The calibrator is suitable for thermocouples, resistance temperature detectors (RTDs), temperature switches, and most temperature measuring instruments, making it a versatile tool for laboratories and industrial maintenance teams.

Q: When should I use a dry block temperature calibrator like this one?

A: You should use a dry block temperature calibrator whenever you need to verify or adjust the accuracy of temperature sensors or devices, either as part of routine maintenance or quality assurance processes.

Q: Where is the ideal environment to use the TCAL 1404/300 calibrator?

A: This calibrator is designed for both laboratory and field use, thanks to its compact design and lightweight build. It is particularly suitable for settings where space and portability are important.

Q: What is the process for calibrating temperature sensors using this device?

A: Calibration involves inserting the sensor into the insert block, setting the required calibration temperature, waiting for stability (0.1C), and comparing the sensor's output with the calibrator's reading to determine accuracy and make adjustments if necessary.

Q: What are the main benefits of using the TCAL 1404/300 miniature calibrator?

A: Major benefits include its rapid heating time, exceptional temperature stability, easy-to-read digital display, and connectivity options. Its compact size improves portability and convenience during sensor checks.
