Lab Model PH/ORP Meter

About Lab Model PH/ORP Meter

Display: 16 Character x 2 Line LCD with backlight

Range : 0 to 14 pH / -1999 to +1999 mV /0 “ 150C

Resolution: 0.01 pH / 1 mV / 0.1C

Accuracy : ± 0.01 pH ± 1 digit / ± 1 mV ± 1 digit /± 0.5C  ± 1 digit

Input Impedance: > 10² Ohms

Temperature Compensation: 0 to 150C Manual / Automatic

Electrode: Combined pH Electrode with BNC attachment

Temperature sensor: Provided with 3-pin female socket

pH / ORP Input connection: BNC socket

Operating Environment: 0 to 50 C / 20 to 95 % RH non condensing

Temperature connection: 3-pin male socket

Power Supply: 230V AC / 50 Hz ± 10%

Overall Dimension in mm: 190 x 185 x 75 ( L x B x H )

Instrument Weight: 1.7 Kg (Approx.)
