ONLINE CONDUCTIVITY CONTROLLER/INDICATOR

About ONLINE CONDUCTIVITY CONTROLLER/INDICATOR

Range (Anyone): 0 to 20S

Resolution: 0.01S to 0.1mS (depends on range)

Accuracy : ± 1 % of range ± 1 digit

Relay Output(Optional): Relay - 1 for Setpoint - 1, Relay - 2 for Setpoint - 2 with 5A Rating

Relay Cyclic delay: 0 to 100 seconds (user adjustable) (only for High & Low control modes)

Alarm Output (optional): Inbuilt audible buzzer with front key reset

Optional Re. Tx. output: Galvanically Isolated 4 - 20 mA

Optional Comm. output: Isolated RS 485

Comm. Protocol: MODBUS RTU

Operating Environment:  -10 to 50C / 10 to 95 % RH Non-Condensing

Cutout Dimension : 92 x 92 mm

Dimension 96 x 96 x 85 mm

Power Supply: 90 to 270V AC / DC 50Hz

Weight: 350 grams (Approx.)
