4 Digit Process Indicator

About 4 Digit Process Indicator

Analog Inputs: 0 - 20 mA, 0 to 70 mV, 0 - 10 V DC, 0.0 “ 400.0 Î (H & L Limit Programmable)

Temperature Inputs: RTD - PT 100, Thermocouple - J, K, R, S, T, B, N, E

Display Range: - 1999 to 9999 (H & L Limit Programmable)

TemperatureRange (H & L Limit Programmable)

RTD - PT 100 (-199.9 to 800.0C )

 TC - J (- 200 to 200C )

 TC - K (- 200 to 1372C )

 TC - R ( 0 to 1765C )

 TC - S ( 0 to 1762C )

 TC - T (- 199.9 to 400.0C )

 TC - B ( 600 to 1800C )

 TC - N (-200 to 1300C )

 TC - E ( -199.9 to 916.0C )

Accuracy: 0.05% FS ±1 counts (Except Thermocouple),  0.05% FS ±2 counts (only for Thermocouple)

Unit selection: C / F (for RTD & TC inputs)

Analog input resolution mV, mA & V: 0.001 / 0.01 / 0.1 / 1 (Selectable)

Temperature Resolution: 0.01 (For RTD - PT 100 input (C) only) /0.1 / 1 C / F

Filter Constant: 1 - 100 % (Adjustable)

Relay Output (optional): 2 Relay (5A rated) with 4 Relay Status Selection, Adjustable Hysteresis, Cyclic Delay

Re-Transmission (optional): Opto Isolated Analog Output 4 - 20 mA or 0 - 10V DC

PC Communication (optional): RS 485 (2 wire) MODBUS RTU protocol

PC Software* (optional): Monitoring, Data logging, Report & graph

Sensor Supply (external): 24 V DC ±10% @ 100 mA

Operating Environment: 0 to 50C / 5 to 95% RH non condensing

Power Supply: 90 to 270 V AC / DC / 50 / 60 Hz

Overall Dimension: 48(H) X 96(W) X 110(D) mm

Cutout Dimension: 44(H) X 90(W) mm

Housing: Panel Mountable ABS Plastic

Weight: 300 grams (Approx.)
