Portable Air velocity meter PAM-204

Name: Portable Air velocity meter PAM-204
Brand: SANSEL INSTRUMENTS & CONTROLS
Price: 32500.0 INR
Availability: InStock

Price 32500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Portable Air velocity meter PAM-204 Specification

Power Consumption
Low Power Consumption

Cable Length
Approx. 1.1 Meter

Response Time
About 1 second

Application
Air Flow Measurement

Interface
LCD Display

Sensor Type
Vane Sensor

Wireless
No

Mounting Type
Handheld

Measurement Range
0.40 to 25.00 m/s

Features
Lightweight, Portable, Easy Operation

IP Rating
IP40

Sensitivity
High

Signal Type
Digital

Operating Temperature
0C to 50C

Product Type
Portable Air Velocity Meter

Material
ABS Plastic Housing

Input
Air Velocity

Output
Digital Display

Function
Measures Air Velocity and Temperature

Usage
HVAC, Environmental Monitoring, Industrial Applications

Resolution
0.01 m/s & 1 fpm

Voltage
9V Battery Operated

Weight
560 Grams (g)

Sensor Head Diameter
72 mm

Data Hold Function
Yes

Storage Temperature
-10C to 60C

Min Air Velocity Measurement
0.40 m/s

Auto Power Off
Yes, after 20 minutes of inactivity

Display Type
Large LCD with Backlight

Units
m/s, km/h, ft/min, knots, mph

Low Battery Indicator
Yes

Battery Life
Approx. 100 hours

Operating Humidity
Less than 80% RH

Max Air Velocity Measurement
25.00 m/s

Portable Air velocity meter PAM-204 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Month

Delivery Time
4 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Portable Air velocity meter PAM-204 About

Measurement Range 01 ms 197 fpm 02 ms 394 fpm 05 ms 984 fpm 010 ms 1967 fpm 020 ms 3937 fpm any once factory Presettable

Resolution 001 ms 1 fpm

Accuracy 5 of Full Scale

Display 28 True Colour TFT with Touch Screen

Application Environment Range 10 to 60 C 0 to 100 RH non condensed

Storage Environment Range 10 to 45 C 10 to 90 RH

Display Refresh Rate 1 second typical

Data Logging Interval 1 sec to 24 Hours user selectable

Data download Via USB typeC to PC software SanselSoft01

Alarm Audible Visible usersettable high low alarms

Calibration 2 point Calibration feature available

Touch sound On Off option available

Battery charging port USB Ctype

Backlight Time Interval Adjustable from OFF to 59 mins 59 secs

Brightness adjustment 10 to 100 user adjustable

Integrated battery 37 V 10000 mAh rechargeable Liion battery

Housing Material ABS with antislip grip silicon cover

Protection Class IP40

Dimension L x B x H 35 x 80 x 165 mm

Instrument Weight 560 g Approx

Effortless Air Velocity Monitoring

The PAM-204 offers a user-friendly experience with its large backlit LCD display, supporting quick unit changes and clear readings in various lighting conditions. Designed for handheld use, it comes with an ergonomic ABS plastic housing, making it highly portable and suitable for frequent field work.

Versatile Measurement Applications

This air velocity meter caters to HVAC technicians, environmental monitoring, and industrial air flow assessments. With a wide operating temperature range (0C to 50C) and humidity resistance (<80% RH), it is built for diverse workplaces including factories, laboratories, and outdoor sites.

Reliable Performance and Convenience

Engineered for extended use, the PAM-204 features a battery life of approximately 100 hours and low power consumption. The auto power-off function helps conserve battery, while the data hold and low battery indicator ensure optimal performance during measurements.

FAQ's of Portable Air velocity meter PAM-204:

Q: How do I operate the Portable Air Velocity Meter PAM-204?

A: To operate the PAM-204, simply power on the device using the button, select your preferred unit of measurement, and position the vane sensor in the airflow. The large LCD with backlight displays real-time air velocity data, and features like data hold let you retain readings for further analysis.

Q: What environments can the PAM-204 be used in?

A: This meter is engineered for HVAC diagnostics, industrial air flow assessments, and environmental monitoring. With an operating temperature range of 0C to 50C and less than 80% RH humidity tolerance, it is suitable for both indoor and outdoor applications in various industries.

Q: When does the auto power-off feature activate on the PAM-204?

A: The PAM-204 automatically powers off after 20 minutes of inactivity. This feature helps prolong battery life, which can last up to around 100 hours of normal usage on a single 9V battery.

Q: Where can I view my air velocity measurements?

A: Measurements are clearly displayed on the large LCD screen, which is backlit for readability in low-light conditions. The interface also provides alerts for low battery and uses digital output for accurate, immediate feedback.

Q: What is the process for measuring air velocity using the PAM-204?

A: Position the 72 mm vane sensor in the airflow you wish to measure. The device senses the air velocity promptly-within about one second-and displays the result. The reading can be held using the data hold function for note-taking or record-keeping.

Q: What benefits does the PAM-204 offer for professional use?

A: Professionals benefit from the device's quick response time, precise readings to 0.01 m/s, multiple unit options, and its lightweight, handheld design. Its high sensitivity, reliability, and extensive battery life make it a practical choice for on-site air flow measurement.
